Description

Specification:

Camera

Image Sensor2 MP CMOS

Signal SystemPAL/NTSC

Max. Resolution1920 (H) × 1080 (V)

Min. Illumination0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR

Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s

Day & NightIR Cut Filter

Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°

Lens

Lens Type2.8 mm, 3.6 mm Fixed Lens

Focal Length & FOV
2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°
3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0°

Lens MountM12

Illuminator

Supplement Light RangeUp to 20 m

Supplement Light TypeSmart,IR,White Light


Frame Rate
TVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
CVBS: PAL/NTSC

Wide Dynamic Range (WDR)Digital WDR

Image Parameters SwitchSTD/HIGH-SAT

Day/Night ModeAuto/Color

White BalanceAuto

Image EnhancementDWDR, BLC, Global

Noise Reduction2D DNR

Image SettingsBrightness, Mirror, Smart IR, Sharpness, AGC

Interface

Video OutputSwitchable TVI/AHD/CVI/CVBS

General

LanguageEnglish

Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)

MaterialPlastic

CommunicationHIKVISION-C

Dimension138.8 mm × 60.9 mm × 57.9 mm (5.465″ × 2.389″ 2.278″)

Approx. 145 g (0.32 lb.)

Power12 VDC ± 25%, Max. 3.3 W

Approval

ProtectionIP67
